#661 Posted: 8/4/2025 11:19:22 AM
Вячеслав Мезенцев

Вячеслав Мезенцев

1,448 likes in 1,753 posts.

Group: Moderator

The topic of scaling is quite difficult to implement and more details are needed to repeat.

In addition, I found that the document contains a ppi value in the header and it changes depending on the resolution at which the document was saved. Perhaps this also affects the display of the document.
Russia ☭ forever, Viacheslav N. Mezentsev
2 users liked this post
Martin Kraska 8/4/2025 9:03:10 PM, ioan92 8/5/2025 2:37:12 PM
#662 Posted: 8/4/2025 9:12:39 PM
Martin Kraska

Martin Kraska

1,247 likes in 2,174 posts.

Group: Moderator

There are two more ppi problems in my setup with changing display devices:
- PNGs produced by by the Snapshot region are of different size depending on where they are created. At least their size in a book processed with pdflatex is different. I have to find out whether this is actually caused by different number of pixels or by some metadata in the PNG file (which I am not aware of so far)
- Screenshots created interactively using Greenshot have correct size if pasted back to SMath in one setup and appear enlarged in the other.

Edit:

It seems that the problems are related to having set a scale factor of 150% if using the internal monitor because of it's limited size (14") . The screenshot pasting and the snapshot region problems are solved, they now behave with the internal monitor the same way as using the external one.

The X-Y plot region, however, now is back to the original problem of much to small axis and tick labels. If I want the axis label to be of the same size as in a text region I have to set the font size to something between 13 (a little smaller) and 14 (a little larger).
BTW, now my dpi setting in the file and in the system information changed from 144 to 96.
Edited 8/4/2025 9:49:03 PM
Martin Kraska Pre-configured portable distribution of SMath Studio: https://en.smath.info/wiki/SMath%20with%20Plugins.ashx
#663 Posted: 8/5/2025 1:24:30 AM
Вячеслав Мезенцев

Вячеслав Мезенцев

1,448 likes in 1,753 posts.

Group: Moderator

SMath Studio compatibility History page Changes

Plugin updated. [BETA]

Changes:

- implementation of a fully functional Animation;
- export to animated GIF;
- user interface improvements and localization;
- deep refactoring and code quality improvement;
Russia ☭ forever, Viacheslav N. Mezentsev
2 users liked this post
Alvaro Diaz Falconi 8/5/2025 7:13:11 AM, sergio 8/5/2025 11:25:46 AM
#664 Posted: 8/5/2025 7:14:55 AM
Alvaro Diaz Falconi

Alvaro Diaz Falconi

1,025 likes in 1,695 posts.

Group: User

Wrote

... - implementation of a fully functional Animation;
- export to animated GIF; ...



It works fine.


pQuiverAnim.sm (58 KiB) downloaded 12 time(s).

Best regards.
Alvaro.
5 users liked this post
Вячеслав Мезенцев 8/5/2025 7:22:17 AM, sergio 8/5/2025 11:25:44 AM, NDTM Amarasekera 8/5/2025 4:59:45 PM, Davide Carpi 8/5/2025 5:10:45 PM, francesco rapuano 8/5/2025 2:50:30 PM
#665 Posted: 8/5/2025 12:29:06 PM
Вячеслав Мезенцев

Вячеслав Мезенцев

1,448 likes in 1,753 posts.

Group: Moderator

Coming soon...


Russia ☭ forever, Viacheslav N. Mezentsev
5 users liked this post
Alvaro Diaz Falconi 8/5/2025 4:39:06 PM, sergio 8/5/2025 1:56:02 PM, ioan92 8/5/2025 2:39:44 PM, Rafael H Padilla Velázquez 8/5/2025 2:54:49 PM, Davide Carpi 8/5/2025 5:10:46 PM
#666 Posted: 8/5/2025 8:51:20 PM
Вячеслав Мезенцев

Вячеслав Мезенцев

1,448 likes in 1,753 posts.

Group: Moderator

And various other things...

Now the new and old functionality of the plugin is being processed by a neural network. The code has become too complex for one person to maintain. Now I only give instructions and am a tester.
I try to check what the AI has written there, it does it in many ways better than me, but it often makes mistakes due to insufficiently clearly stated tasks.

Edited 8/5/2025 9:05:26 PM
Russia ☭ forever, Viacheslav N. Mezentsev
2 users liked this post
Alvaro Diaz Falconi 8/6/2025 1:52:06 AM, francesco rapuano 8/6/2025 11:02:34 AM
#667 Posted: 8/6/2025 1:56:29 AM
Alvaro Diaz Falconi

Alvaro Diaz Falconi

1,025 likes in 1,695 posts.

Group: User



Starting at (-2,2)


Van der Pol oscillator.sm (60 KiB) downloaded 4 time(s).

with an improved quiver version.

Best regards.
Alvaro.
Edited 8/6/2025 6:17:18 AM
